技术建筑师Eduardo Vázquez López合作者Federico Farina，Ronit Shmaryhu More

Structures Santiago Bermejo Installations IDD Consultores Technical Architect Eduardo Vázquez López Collaborators Federico Farina, Ronit Shmaryahu More Specs Less Specs

架构师提供的文本描述。该项目是在西班牙南部塞维利亚郊区的住宅区扩建的。

Text description provided by the architects. The project was built in an area of residential expansion in the outer suburb of Seville, in the south of Spain.

 © Roland Halbe

罗兰·哈贝

小面积的地块和高的住房密度，需要一个法庭式的解决方案。庭院作为一个社会互动的区域发挥了关键作用，并使46套公寓(2或3间卧室)有可能实现两种前景-在内部庭院和街道上。

The small size of the plot and the high housing density that was required suggested a court-type solution. The patio played a key role as an area for social interaction and made it possible to achieve the objective of giving the 46 apartments (2 or 3 bedrooms) two prospects – on the inner courtyard and on the street.

 © Roland Halbe

罗兰·哈贝

每套公寓都有一个带有服务设施的中央通道。卧室有很高很窄的窗户，在北面，而客厅和厨房在南面有很大的窗户。露台被设计成客厅的室外延伸部分，在夏季的几个月里，它们的投影遮住了大窗户，同时允许太阳在冬季进入。这意味着所有的公寓都暴露在两边，交叉通风。

Each apartment is divided by a central access with service facilities. The bedrooms have tall, narrow windows and are on the northern side while the sitting rooms and kitchens that give onto the souther side have large windows. The terraces are designed as outdoor extensions of the sitting rooms and their projections shade the large windows during the summer months while allowing the sun to enter during the winter. This means that all the apartments are exposed on both sides, with cross ventilation.

 © Roland Halbe

罗兰·哈贝

在底层，商店被垂直流通系统的入口隔开，从一边穿过街区，连接内部庭院和道路。该建筑群设有停车位和每间公寓的储藏室。

On the ground floor, shops are separated by entrances to the vertical circulation systems which go through the block from one side to the other, linking the internal courtyard and the road. The complex is complete with parking spaces and store rooms for each apartment.

 © Roland Halbe

罗兰·哈贝

这些材料是用于低收入住房的材料，是以简单的方式完成的，比如有不同纹理和细微差别的预着色石膏板，这取决于要制造的表面。在五种不同的合金中使用波纹锌板-一楼不透明，公寓上层有微孔-给人的印象是，一天中有颜色和反射的空间发生变化。

The materials, which are those for low-income housing, are finished in simple ways, such as pre-coloured plasterwork with different textures and nuances, depending on the surface to be made. The use of corrugated zinc panels in five different alloys – opaque on the ground floor and microperforated on the upper floors of the apartments – gives the impression of a space with colours and reflections that change during course of the day.

Architects Gabriel Verd Arquitectos

Location Avenida de las Civilizaciones, 3, 41927 Mairena del Aljarafe, Sevilla, Spain

Category Housing

Architect in Charge Gabriel Verd

Design Team Gabriel Verd, Simone Solinas

Area 6738.0 sqm

Project Year 2011

Photographs Roland Halbe
