Cliff House Hyde + Hyde Architects

2014-09-03 01:00

工料测量师米尔德里德豪威尔斯主承包商自行建造结构工程师CD Gray

Quantity Surveyor Mildred Howells Main Contractor Self build Structural Engineer CD Gray & Associates M&E Consultant SABA Specific environmental targets Code for Sustainable Homes Level 4 Manufacturers Loading... More Specs Less Specs

 Courtesy of Hyde + Hyde Architects

海德建筑师

架构师提供的文本描述。这座新家坐落在俯瞰布里斯托尔海峡(Bristol Channel)与大西洋交汇的大海的石灰岩悬崖上，让我们的客户可以在不断变化的海洋光线和氛围中生活。这座住宅的建筑完全集中在这些景观上，主要居住空间位于一楼，并有严格的简约，以实现低碳住宅。

Text description provided by the architects. Perched up high on a limestone cliff overlooking the sea where the Bristol Channel meets the Atlantic Ocean, the new home allows our clients to live among the ever changing light and atmosphere of the ocean. The architecture of the home is one of total focus on these views, with the main living spaces located on the first floor, combined with a strict brief to achieve a low carbon home.

设计要素确保建筑物的长期能源性能将是例外的-使用空气源热泵，为湿地板下采暖系统提供整个房屋的机械热回收通风。热水储存在汽缸中，辅以太阳能和空气源热泵。

Elements of the design ensure that the building’s long term energy performance will be exceptional - utilising an air source heat pump feeding a wet under-floor heating system with whole house mechanical heat recovery ventilation. Hot water is stored in cylinder tanks assisted by solar thermal and the air source heat pump.

 Courtesy of Hyde + Hyde Architects

海德建筑师

该建筑物是由绝缘混凝土模板建造的，使其具有高度绝缘的空气密闭周界。为了平衡建筑物织物的沉重感，引入了雪松包层阳台框架，将重点放在海景上，垂直和水平平面创造了一系列复杂的空间层。倾斜的百叶窗旨在帮助创建一个半透明的物体，同时避免俯瞰，并提供防风保护。它还创造了适应性强的雨檐、遮阳、汽车盖和入口遮阳罩。

The building is constructed from insulated concrete formwork giving it a highly insulated air tight perimeter. To balance the heaviness of the building fabric a cedar clad balcony frame is introduced to focus on sea views, with vertical and horizontal planes creating a series of sophisticated spatial layers. Angled louvers are intended to help create a semi-transparent object whilst avoiding overlooking and to provide wind protection. It also creates adaptable rain canopies, solar shading, cover for a carport and an entrance canopy.
