架构师提供的文本描述。UBM住房项目是穆利亚大学(Universitas Bunda Mulia)对雅加达世界上最严重的交通问题的回应，因为雅加达是人口超过1，000万的特大城市之一，而且每年有越来越多的校外学生入学。酒店距离校园仅5分钟车程，11层17，600平方米的学生住宅设施包括室内迷你市场、多用途客房、学生休息室、自助餐厅、洗衣房、自动取款机和内部庭院下面的停车场。

Text description provided by the architects. The UBM Housing project is Universitas Bunda Mulia’s response to Jakarta’s world’s worst traffic problem as one of the megacities with population over 10 million and the growing number of out-of-town students enrolling into the university each year. Located within a five-minute walk from campus, the eleven storey 17,600 square meter student housing facility includes on-site mini market, multipurpose rooms, student lounge, cafeteria, laundry, ATM and parking garage below the inner courtyard.

 Typical Floor Plan

该项目通过在宜居的高密度环境中开发一个充满活力的城市中心来解决城市密度和住房成本问题的挑战，同时通过在不牺牲隐私的情况下提供交互空间和视觉连接来鼓励社区精神。该设计解决了当代社会对共享空间和社会需求的关切，同时通过提供热带地区特有的多种室内/室外空间来回应共同生活和个性问题。

The project approaches the challenge of urban density and housing cost problems by developing a vibrant urban center in a livable high-density environment while encouraging community spirit by providing interaction spaces and visual connections without sacrificing privacy. The design addresses concerns of shared space and social needs in a contemporary society and simultaneously responds to issues of shared living and individuality by offering a multiplicity of indoor/outdoor spaces specific to the tropical context.

 © Fernando Gomulya

c.Fernando Gomulya

自然照明单元被放置在工地周边，作为一个薄薄的包裹着一个开放的内部空间，使用一个简单的设计策略来创建一个中心庭院，具有吸引人的功能和审美品质。单元与露天双负荷走廊相连，向南角开放，供电梯大堂使用。北角的厨房和更多的开口向庭院共享空间，以允许交叉通风和日光渗透到走廊，这也有助于打破长廊步行的经验。从地板到天花板的高而窄的窗户被选中以发出尽可能高的光，同时仍然允许单位在地板上反射光。

Naturally lit units are placed on the perimeter of the site as a thin mass wrapping an open inner space that uses a simple design strategy to create a center courtyard with attractive functional as well as aesthetic qualities.Units are connected with open-air double-loaded corridors with openings towards south corners for elevator lobbies, north corners for kitchens and more openings towards the courtyard for shared spaces to allow for cross ventilation and daylight to penetrate into the corridors which also help to break down the long corridor walking experience. Tall and narrow windows spanning from floor to ceiling were chosen to emit light as high up as possible, while still allowing for reflections on the floors for the units.

 © Fernando Gomulya

c.Fernando Gomulya

一个模块化的立面系统，加上预制的混凝土构件，使人们能够负担得起和合理的建造。它还允许一个系统在视觉上投射出大学的品牌形象。五颜六色的条纹掩盖正面的巨大体积沿内院。通过分配垂直条纹的颜色口音，体积看起来是不同的，但也是一个整体的一部分。立面上的建筑投影也提供了深度和轻盈，同时也提供了必要的防晒和防雨功能。沿着内部庭院的外观的投影被旋转，作为单位的隐私屏幕。

A modular façade system together with prefabricated concrete elements allows for an affordable and rational construction. It also visually allows for a system to project the university’s branding identity. Colorful stripes camouflage the facades’ massive volume along the inner courtyard. By distributing the vertical stripe of color accents, the volume appears varied, yet part of a whole. Architectural projections on the façade also give a depth and lightness while allowing the necessary sun and rain protection. The projections along inner courtyard’s façade were rotated to act as privacy screen for the units.

 © Fernando Gomulya

c.Fernando Gomulya

Architects ID-EA

Location Jakarta, Special Capital Region of Jakarta, Indonesia

Category Apartments

Design Architect Elsye Alam

Executive Architect PT. Ita Rahayu Utama

Project Year 2014

Photographs Fernando Gomulya
