Catholic Suzuka Church Alphaville Architects

2017-07-26 20:00
 © Toshiyuki Yano
c.Yano Toshiyuki Yano
架构师提供的文本描述。为了应对苏祖卡外国天主教社区的急剧增长,不仅需要一个新的宗教空间,还需要一个新的宗教空间来进行崇拜和社会互动。由阿尔法维尔建筑师提出的天主教苏祖卡教会是一个多功能的结合,包括一个礼拜堂、一个社区大厅和牧师的住所。该项目位于本田汽车工业基地Suzuka,位于两条主要街道的交叉路口,其中一条是新建的高速公路,其余一条是江户时期以来连接东京和大阪的一条古道。
Text description provided by the architects. Responding to a dramatic growth in the foreign Catholic community in Suzuka, a new religious space is needed not only for worships but also social interactions. The Catholic Suzuka Church, presented by the Alphaville Architects, is an integration of multiple functions including a chapel, a community hall and residences for priests. Located in Suzuka, where the HONDA motor industry bases, the presented project is sitting on the cross junction of two major streets, with one being a newly built motorway and the remaining one being an ancient road connecting Tokyo and Osaka since Edo period.
 © Toshiyuki Yano
c.Yano Toshiyuki Yano
 Axonometric


 © Toshiyuki Yano
c.Yano Toshiyuki Yano
该项目的特点是一个富有表现力的屋顶,将所有的功能空间包装起来。它的形状是多个对角线拱相互重叠与缝隙。这是受城市周围令人叹为观止的山景的启发,并使市民想起了自然的优雅。
The project features an expressive roof which wraps up all the functional spaces. It is shaped as multiple diagonal arches overlapping each other with gaps. This was inspired by the stunning mountain scape surrounding the city, and reminds citizens of the natural elegance.
 © Toshiyuki Yano
c.Yano Toshiyuki Yano
为了在星期日处理拥挤的人群,整个体积被提升,以最大限度地增加车位,而不会缩小其他功能区域。屋顶每隔5米就被分割成几块-指的是停车场模块-让天窗将南方的自然光引入室内。通过两个倾斜的楼梯连接起来,二楼的山庄和入口大厅为社交活动和从高度机动的城市提供缓冲提供了一个广场。
To handle crowds on Sundays, the whole volume is lifted to maximize the car parking space underneath without shrinking the other functional areas. The roof is split into pieces every five meters – referring to the parking lot module – for skylights to introduce the southern natural light to the interiors. Connected by two gently inclined staircases, the pilotis and the entrance lobbies on the second floor define a plaza for social events and buffering from the heavily motorized city.

参照“诺里的数字/地面理论”,大厅被设计成城市道路的延伸,操纵“内外”空间之间的关系,使教堂会聚在一起,让人们可以轻松地进入教堂。
Referring to the “Nori’s figure/ground theory”, the lobby is designed as an extension of the city pathways, manipulating relationships among the “inside-out” spaces converging at the church that allow easy approaches.
 © Toshiyuki Yano
c.Yano Toshiyuki Yano
 Structural Diagram


 © Toshiyuki Yano
c.Yano Toshiyuki Yano
以其生动的姿态,这一项目超越先例,增强可及性,将崇拜转化为日常生活哲学,并以自然光的瀑布将人类连接到神圣之地。
With its lively gesture, this project surpasses precedents with enhanced accessibility, translating worships into daily-life philosophy and bridges mankind to the holy with falls of natural light.
 © Toshiyuki Yano
c.Yano Toshiyuki Yano





















































Architects Alphaville Architects
Location Japan, 〒513-0801 Mie-ken, Suzuka-shi, Kanbe, 3 Chome−17−5, カトリック鈴鹿教会
Architects in Charge Kentaro Takeguchi, Asako Yamamoto
Area 1588.85 m2
Project Year 2015
Photographs Toshiyuki Yano
Category Churches
