Álika Residencial JRA Arquitectos

2018-01-09 20:00
阿利卡住宅位于一处形状不规则的房产上,总面积为48.24公顷,位于维拉克鲁斯市北部。它分为5个阶段,每个阶段都是一个超级块,内部有一个带有入口控制的车辆电路。
Álika Residencial is located on an irregularly shaped property with a total area of ​​48.24 hectares, located in the northern part of the city of Veracruz, Veracruz. It is divided into 5 stages, each of which is a super block with an indoor vehicular circuit with access control.
 © Santiamén
(桑蒂亚曼)
第一阶段从道路进入并通过相邻的分区,有一个有控制访问的警卫室。还有陈列室,我们的销售办公室,以创新的设计和绿色的墙壁销售,发挥其城市地标功能,成为阿尔卡的象征。
The first stage which is accessed from the road and through the neighboring subdivision, has a guardhouse with controlled access. There is also the showroom, our sales office, which sells with the innovation of its design and its green walls, fulfilling its urban landmark function by becoming the symbol of Álika.

穿过通道的是公园,这是一个广袤的绿色区域,有当地树木的种类,这些树木被重新种植在同一片土地上。我们有停车场、游乐场、野餐区和一个小湖。
Passing the access is the park, an extensive green area with species of native trees of the area, which were replanted of the same property. We have parking places, playgrounds, picnic area and a small lake.
 © Santiamén
(桑蒂亚曼)
这个开发项目拥有所有的地下设施。道路的设计力求在繁忙时间保持交通畅通,并将公共交通集中到某些主要走廊,同样优先考虑行人和使用其他交通路线,如自行车。
The development has all the underground facilities. The design of the roads seeks to have fluid traffic at peak times, as well as concentrate public transport only to certain main corridors, in the same way priority is given to pedestrians and to the use of alternative transportation routes, such as bicycles.
 © Santiamén
(桑蒂亚曼)
城市环境(服务、流动性、密度等)
• Urban context (services, mobility, density, etc.)
该房产位于北部城市地段内,其土地用途与周围的开发项目相一致,核定密度为4 000套住房,尽管在阿利卡目前的项目中,只有2 400套住房可提供更大的绿地和共存。
The property is located within the urban spot of the north, its land use is housing in congruence with the surrounding developments, with an approved density of 4,000 homes, although in the current project of Álika have only 2,400 homes to offer Greater green areas and coexistence.
 © Santiamén
(桑蒂亚曼)
这是一个获得剩余价值的地方,因为多年来,在步行距离内开发了大型商业区,包括所有服务、学校、便利店、电影院和广场。它能在几分钟内连接到维拉克鲁斯市中心,这要归功于快速的通讯线路和公共交通线路的可用性。
It is a location that has gained surplus value, as over the years large commercial areas have been developed with all services, schools, convenience stores, cinemas and squares within walking distance. It connects to the city center of Veracruz in a few minutes thanks to the fast communication routes and the availability of public transportation routes.
 Section 01
Section 01
目前,有7条不同的公共汽车路线通过阿利卡的通道。
Currently, 7 different bus routes pass through the access of Álika.
环境背景
• Environmental Context
在Lika,建筑物的地形是设计的一个重要部分,因为低地的不均匀度从25.00 MSNm到最高点的60.00 MSNm不等,在使用金属模具的阶段实现了最大坡度2.5%的渐变。土地的流动对发展至关重要,因为只有土地才能填满,而不增加更多的物质。同样,考虑到地形的自然降雨,设计了卫生学和雨网。
In Álika, the topography of the building was an essential part of the design, since the unevenness ranges from +25.00 msnm in the lower areas to +60.00 msnm in the highest points, and a gradual fading with a maximum slope of 2.5% was achieved in the stages where metal mold is used. The movement of land was crucial for development, as it would be filled only with the land without adding more material. In the same way, the sanitary and pluvial network was designed respecting the natural rainfall of the terrain.
 © Santiamén
(桑蒂亚曼)
社会背景(用户概况、该地区的社会经济水平、经济职业等)
• Social Context (profile of users, socioeconomic level of the area, economic vocation, etc.)
使用者的概况主要是有10岁以下子女的家庭,平均4人,也有单身人士和老年人,但百分比较低。客户的社会经济水平分为C和C两部分,在大多数情况下,他们是买第一套房子的人,或者是居住在社区的人,他们认为这个项目是北方最好的街区。
The profile of the users is mainly families with children under 10 years old, integrated of 4 people on average, there are also single people and older adults although in a lower percentage. The socioeconomic level of clients is in segments C and C +, in most cases they are people who are buying their first home or people who lived in the neighborhoods and identify the project as the best block in the north.
 © Santiamén
(桑蒂亚曼)
