Holm Place OB Architecture

2018-03-07 13:00
 © Martin Gardner
马丁·加德纳
架构师提供的文本描述。Holm Place是南沃恩伯勒村的一处新住宅。这片占地0.12公顷的建筑位于17世纪南沃恩伯勒保护区的二级建筑-庄园苑的上花园里。简短的是创建一个典型的现代住宅,以容纳四间卧室与开放式的居住空间。设计的目的是与花园有直接的关系,最大限度地利用光线,模糊内外之间的界限。
Text description provided by the architects. Holm Place is a new dwelling in the village of South Warnborough. The 0.12-hectare site is located in the upper garden of Manor Court, a 17th century Grade II listed building in the South Warnborough Conservation Area. The brief was to create an exemplary modern home to accommodate four bedrooms with open-plan living spaces. The design aims to have a direct relationship to the garden, maximizing light and blurring the threshold between inside and outside.
 © Martin Gardner
马丁·加德纳
L字形图被推到场地的边缘,以保护所列建筑物周围的绿色环境。高地处理和建筑材料采取他们的指示从庄园法庭,使用一个简单的托盘砖,木材,非白色渲染,玻璃和锌。建筑布置在一个3米的结构网格上,内部和外部都有表达,以使构图清晰有序。
The L-shaped plan is pushed to the edges of the site to preserve the green setting around the listed building. The elevational treatment and building materials take their cues from Manor Court, utilizing a simple pallet of brick, timber, off-white render, glass, and zinc. The building is arranged on a 3m structural grid, which is expressed both internally and externally to give clarity and order to the composition.
 © Martin Gardner
马丁·加德纳
 Ground Floor Plan


 © Martin Gardner
马丁·加德纳
对于向北的外墙,用砖和锌包覆系统定义了实心外壳。锌参考了当地的农业建筑和庄园的领导工作。内部庭院高度采用木材覆盖层,垂直比例与庄园法院的面板相匹配。Iroko的选择是因为它的耐用性和颜色,将天气下降,以匹配现有建筑的颜色色调。
For the external walls facing north, a solid enclosure was defined using brick and a zinc cladding system above. The zinc references the agricultural buildings in the local area and the leadwork on Manor Court. Timber cladding was employed for the internal courtyard elevations with the vertical proportions matching the panels on Manor Court. The iroko was chosen for its durability and color that will weather down to match the color tone of the existing building.
 © Martin Gardner
马丁·加德纳
底层住宿有两个明显的区域,北翼有开放式的厨房、餐饮、居住空间和西侧的卧室住宿。在这两个区域之间形成联系的是入口大厅、走廊和双高楼梯.循环是由一个最小的柱状结构来定义的,它形成了一个面向围墙花园的修道院。一楼的主卧室套房设计有一个亲密的露台,可以看到乡村的广阔景色。
The ground floor accommodation has two distinct zones, the north wing containing an open-plan glazed kitchen, dining, living space and the west wing the bedroom accommodation. Forming a connection between these two areas is the entrance hall, gallery and double-height staircase. The circulation is defined by a minimal column structure that forms a cloister facing the walled garden. The master bedroom suite at first floor is designed with an intimate terrace that takes in the wide views of the countryside.
 © Martin Gardner
马丁·加德纳







































Architects OB Architecture
Location Hook, United Kingdom
Lead Architects James Chapman
Area 399.0 m2
Project Year 2017
Photographs Martin Gardner
Category Houses
Manufacturers Loading...
