Seis Building SML ARQUITECTOS + MATHIAS KLOTZ

2018-03-12 13:00
 © Nico Saieh
c.Nico Saieh
架构师提供的文本描述。这项任务包括在智利圣地亚哥Cerro San Luis南坡上的一个陡坡上投射六套豪华公寓。这座山是“El Golf”社区内的一种岛屿,这个地区已经变成了一个以商业和办公为主的地区,它仍然有一个住宅规模,有一些房屋,其中一些具有有趣的建筑质量、低层和梯级建筑。
Text description provided by the architects. The assignment consisted in projecting six luxury apartments in a terrain with a steep slope on the southern slope of Cerro San Luis located in Santiago de Chile. This hill, which is a kind of island within the "El Golf" neighborhood, a district that has mutated into a predominantly commercial and office area, still has a residential scale, with houses, some of them with interesting architectural quality, low rise and terraced build

该建筑的建造方式是在第一层向“El Golf”社区放置四个具有相同特征的复式单元,而后两个单元位于较高层,故意将较低单元的立面层安置起来,以减少建筑物朝向公共空间的存在,并利用场地的坡度。最后这些公寓位于较低单元之上的平台上,与物业的上层相连,因此,与前几个部门不同的是,它们的四个立面向外部开放。
The building is created by placing four duplex units with the same characteristics in the first levels towards the "El Golf" neighborhood, while the last two are located on the upper level, deliberately settling the façade level of the lower units in order to reduce the presence of the building towards the public space and take advantage of the slope of the site. These last apartments are located on a platform built over the lower units and connecting with the upper level of the property, so that, unlike the first departments, have their four facades open to the

 © Nico Saieh
c.Nico Saieh
大梯田被提出了一个系统的铝锌布-太阳,涵盖整个高度的复音在最后。这不仅允许在这些露台中创造更多隐私的角落,而且还允许四个较低的单位看起来像四个棱柱木卷,上面的单位是支持的。
Large terraces are proposed with a system of Aluzinc brise-soleil that cover the entire height of the duplexes in the end. This not only allows to create corners of greater privacy among these terraces but also allows the four lower units to appear clearly identified as four prismatic wooden volumes on which the upper units are supported.
 © Nico Saieh
c.Nico Saieh
内部结构是一个开放的计划,很少有结构元素,因此随着时间的推移,它允许不同的配置方案和演化。只有浴室和厨房被认为是永久性的围护设施,其设计目的是充分服务于所有拟议的方案备选方案,因为今后很难对上述围护设施进行干预。
The interiors are structured as an open plan with few structural elements, so that it allows different configuration alternatives and evolutions over time. Only the bathrooms and kitchens have been considered as permanent enclosures, which were designed to adequately serve all the proposed program alternatives, given the future difficulty of intervening the facilities of said enclosures.
 © Nico Saieh
c.Nico Saieh
两个上层单元都有一个露台和天井,以及一个观察点,甲板上有一个琉璃池,在那里你可以欣赏到城市的美景。
The two upper units have a terrace and patio on all sides as well as an observation point with a glazed pool on the deck, from which you get a privileged view of the city.



























Architects MATHIAS KLOTZ, SML ARQUITECTOS
Location El Quisco 3160, Las Condes, Región Metropolitana, Chile
Architect in Charge SML ARQUITECTOS + MATHIAS KLOTZ
Area 1306.31 m2
Project Year 2014
Photographs Nico Saieh
Category Residential
