建筑师提供的文字说明。该大楼位于M.M.M.的地块内，用于改造布尔努（活动区22@）的工业区。

Text description provided by the architects. The building is located in a plot included in the field of M.P.G.M. For the renovation of the industrial areas of Poble Nou (district of activities 22 @).

Text description provided by the architects. The building is located in a plot included in the field of M.P.G.M. For the renovation of the industrial areas of Poble Nou (district of activities 22 @).

 © Antonio Navarro Wijkmark

c Antonio Navarro Wijkmark

 © Antonio Navarro Wijkmark

c Antonio Navarro Wijkmark

本项目为SB连锁酒店开发了一座拥有235个客房的四星级高级酒店大楼(4*S)，提出了一种新的酒店概念。该大楼由3层地下室、底层、8层房间和屋顶层组成。地下室2层和-3层用于停车场、技术室和仓库。地下室-1层是专为公众而设的大厅、会议室和大型餐厅。半覆盖露台允许进入这些房间的自然光。这些庭院有一个绿色的墙处理他们的墙壁，将采取从外部空间的底层。此外，楼层设有厨房和工作人员区。一楼为酒店正门，设有接待区、大堂和酒吧区。正门在一个有盖的大入口下面，允许客人下船。在客户通道的另一边是通往​​停车场和出入区的入口坡道。在后面的建筑周围的空间，给老庞斯工厂立面，作为一个酒吧的露台，同时创造了一个与其他自由空间的街区综合空间。

The present project develops a 4-star superior hotel building (4 * S) with 235 rooms for the SB hotel chain, where a new concept of hotel is proposed. The building consists of 3 floors basement, ground floor, 8 floors of rooms and a rooftop floor. The basement floors -2 and -3 are intended for parking, technical rooms and warehouses. The basement floor -1 is intended for halls, meeting rooms and a large dining room for the general public. Semi covered patios allow the entrance of natural light to these rooms. These patios have a green wall treatment for their walls that will take presence from the exterior space of ground floor. In addition, the floor is complete with kitchen and staff area. The ground floor is intended for the main entrance of the hotel, with reception, lobby and bar area. The main entrance is underneath a large covered entrance that allows the hotel guests to disembark. On the opposite side of the customer access is the access ramp to the parking lot and access area of ​​the staff. The space that surrounded the building at the back, giving facade to the old Pons Factory, serves as a bar terrace, while creating an integrated space with the other free spaces of the block.

The present project develops a 4-star superior hotel building (4 * S) with 235 rooms for the SB hotel chain, where a new concept of hotel is proposed. The building consists of 3 floors basement, ground floor, 8 floors of rooms and a rooftop floor. The basement floors -2 and -3 are intended for parking, technical rooms and warehouses. The basement floor -1 is intended for halls, meeting rooms and a large dining room for the general public. Semi covered patios allow the entrance of natural light to these rooms. These patios have a green wall treatment for their walls that will take presence from the exterior space of ground floor. In addition, the floor is complete with kitchen and staff area. The ground floor is intended for the main entrance of the hotel, with reception, lobby and bar area. The main entrance is underneath a large covered entrance that allows the hotel guests to disembark. On the opposite side of the customer access is the access ramp to the parking lot and access area of ​​the staff. The space that surrounded the building at the back, giving facade to the old Pons Factory, serves as a bar terrace, while creating an integrated space with the other free spaces of the block.

整个外部空间的城市化是城市公共使用街区内部的连续体的一部分。一至八年级的植物主要以室内植物为主。8楼为这一层的套房建造了一个周边露台。顶层设有游泳池、日光浴室、健身房、酒吧区和露台，可欣赏城市美景。主立面力求给建筑一个独特的形象，同时对功能、阳光和城市规模作出反应。这四个正面有相同的处理，其中主要是垂直的组成部分，提供开放的窗户的房间。表面处理采用大规格面板，微水泥光洁度高.

The whole urbanization of the outer spaces is part of an urban continuum of public use of the interiors of the block. The plants on grade 1 to 8 are mainly destined to rooms. The 8th floor generates a perimeter terrace for the suites rooms of this floor. The top floor hosts a swimming pool, solarium, gym and bar area and terrace with great views of the city. The main façade seeks to give a unique image to the building, while giving a response to functionality, sunshine and urban scale. The 4 facades have the same treatment, where predominates the vertical component that give the openings of the windows of the rooms. The surface treatment is with large format panels with micro-cement finish of light tones.

The whole urbanization of the outer spaces is part of an urban continuum of public use of the interiors of the block. The plants on grade 1 to 8 are mainly destined to rooms. The 8th floor generates a perimeter terrace for the suites rooms of this floor. The top floor hosts a swimming pool, solarium, gym and bar area and terrace with great views of the city. The main façade seeks to give a unique image to the building, while giving a response to functionality, sunshine and urban scale. The 4 facades have the same treatment, where predominates the vertical component that give the openings of the windows of the rooms. The surface treatment is with large format panels with micro-cement finish of light tones.

 © Antonio Navarro Wijkmark

c Antonio Navarro Wijkmark

不同的纹理取决于几何雕刻是如何在每个面板上再现。每个窗口的几何形状都是通过垂直于立面的一片来完成的，根据植物的不同，它在窗口的一侧和一侧的位置都会发生变化。这件作品结合了一个照明系统，通过一条LED，将照亮建筑物。采用大幕墙开口、底层玻璃和地板式通风立面解决了立面技术。

Different textures differ depending on how a geometric engraving is reproduced on each panel. The geometry of each window is completed with a piece perpendicular to the facade that varies its position to side and side of the window depending on the plant. This piece incorporates a lighting system that, through a strip of LEDs, will illuminate the building. The façade technology is solved with large curtain wall openings glass in ground floor and ventilated facade in the floor type.

Different textures differ depending on how a geometric engraving is reproduced on each panel. The geometry of each window is completed with a piece perpendicular to the facade that varies its position to side and side of the window depending on the plant. This piece incorporates a lighting system that, through a strip of LEDs, will illuminate the building. The façade technology is solved with large curtain wall openings glass in ground floor and ventilated facade in the floor type.

 © Antonio Navarro Wijkmark

c Antonio Navarro Wijkmark

Architect Batlle i Roig Arquitectura

Location Carrer de Badajoz, 148-154, 08018 Barcelona, Spain

Architects authors of the work Enric Batlle, Joan Roig

Design Team Laura Quintana, Joan Batlle, Yago Cavaller

Area 15400.0 m2

Project Year 2017

Photographer Antonio Navarro Wijkmark

Category Hotels
