架构师提供的文本描述。该项目是台湾最大的汽车代理控股公司和宇集团的总部办公大楼。设计的挑战在于塑造一座具有建筑美学的标志性建筑，同时也代表了企业的精神，即在专业领域追求创新理念。

Text description provided by the architects. This project is the headquarters office building of Hoyu Group, the biggest car agency holding company in Taiwan. The design challenges is to shaping a landmark building with architectural aesthetics yet representing the spirit of enterprise that is to pursue innovation concept in the specialized field.

Text description provided by the architects. This project is the headquarters office building of Hoyu Group, the biggest car agency holding company in Taiwan. The design challenges is to shaping a landmark building with architectural aesthetics yet representing the spirit of enterprise that is to pursue innovation concept in the specialized field.

阿卡德设计：风，运动，和繁荣的主要概念来自流体力学，如汽车设计神话。流体的运动忠实地对相应的反应堆作出反应，在表面上形成一种风向交叉的节奏。

Façade design: Wind, Motion, and Flourish The Main concept comes from the fluid mechanics, as car design mythology. The fluid movement faithfully react to the corresponding reactors to create a rhythm on façade that the wind has crossed.

Façade design: Wind, Motion, and Flourish The Main concept comes from the fluid mechanics, as car design mythology. The fluid movement faithfully react to the corresponding reactors to create a rhythm on façade that the wind has crossed.

 Analysis Diagram

我们用蒲公英作为最好的培养基来表达流动的表现。采用蝗虫算法编辑器，由双向正交和三向斜面组成。第一地板和顶部地板空间的南侧向内缩回。风就像一把锋利的刀片，形状像钻石一样。Faherade玻璃单元显示了被吹走的蒲公英的动态。

We use dandelion as the best medium to express flowing performance. Practicing with Grasshopper algorithm editor, the façade is composed of two-way orthogonal and three-way inclined planes. The south side of the first floor and the top floor space are retracted inward. The wind is like a sharp blade, and the shape is carved like a diamond-shape. The façade glass unit shows the dynamic of the blown away dandelion.

We use dandelion as the best medium to express flowing performance. Practicing with Grasshopper algorithm editor, the façade is composed of two-way orthogonal and three-way inclined planes. The south side of the first floor and the top floor space are retracted inward. The wind is like a sharp blade, and the shape is carved like a diamond-shape. The façade glass unit shows the dynamic of the blown away dandelion.

模块化幕墙采用模块化设计来实现玻璃面板的节拍。钢是用来支撑玻璃的。在相同的模式下，两个三角形形成一个完整的矩形单元。建筑围护结构由1，447个玻璃单元组成，其中102个单元沿对角线轴旋转，在正面形成特殊的节奏。

Modularization Curtain Wall The curtain wall uses a modular design to achieve the rhythm of glass panels. The steel is used to support the glass. In the same mode, two triangles form a complete rectangular unit. The building envelope consists of total 1,447 glass units, of which 102 units are rotated along the diagonal axis to form a special rhythm on the facade.

Modularization Curtain Wall The curtain wall uses a modular design to achieve the rhythm of glass panels. The steel is used to support the glass. In the same mode, two triangles form a complete rectangular unit. The building envelope consists of total 1,447 glass units, of which 102 units are rotated along the diagonal axis to form a special rhythm on the facade.

 West elevation

西面高程

通过调整幕墙总成的位置、尺寸和连接，使主对角线斜向倾斜，使正交的二次网架排列一致。舞动单元在四面都有斜向或向外倾斜的斜面。当连接时，其他相邻单元仍必须保持正交性，这将成为装配上的一种创新方式。(B).

By adapting the position, size, and connection of the curtain wall assembly, the main diagonal lines are diagonally inclined and the orthogonal secondary grids are arranged coincidently. The galloping unit has obliquely inward or outward bevels on all four sides. When joining, other adjacent units must still maintain orthogonality which becomes an innovative way on the assembly. ­

By adapting the position, size, and connection of the curtain wall assembly, the main diagonal lines are diagonally inclined and the orthogonal secondary grids are arranged coincidently. The galloping unit has obliquely inward or outward bevels on all four sides. When joining, other adjacent units must still maintain orthogonality which becomes an innovative way on the assembly. ­

Architects r.c. Architects

Location No.433, Songjiang Rd., Zhongshan Dist., Taipei City 104, Taiwan

Lead Architect Ronghao Chang

Local Architect / Construction Administration LSW Architects

Design Team Chengxuan Tsai, Hongyi Dai, Tingrui Yen, Yihua Wang, Pinzhi Wu, Jinming Chang

Area 13520.0 m2

Project Year 2018

Photographs Kyle Yu

Category Office Buildings

Manufacturers Loading...
